Lock Type: Mortise
Battery: 4x AA alkaline cells
5 Unlocking modes: Fingerprint,
PIN Access,
NFC Access Card,
Atomberg Home App,
Remote OTP Access and
Mechanical Key
Product dimensions: Body: L- 270.5 mm W- 68.5 mm H-76mm (For Door Gap reference)
Handle lever length: 140 mm
Mortise: 147 mm (height), 22 mm (width), 82.5 mm (breadth)
Safety mechanisms: Restricted access for 1 minute after 5 false PIN attempts
Snoop protection for keypad
Security: App to Lock Communication over Bluetooth: Data encrypted using AES128
App to Cloud Communication: Data encrypted using AES256 and transmitted over HTTPS secure channel
Warranty: 2-Years
Main Materials: Steel, SS304
Materials Used: Front & Back Panel : Coated Cast Iron, Plastic ABS& PP
Mortise : SS304, Normal Steel
NFC Access Card: Plastic PVC
Spindle : MS, Zinc Alloy
Emergency Power Backup Port: 5V Type-C based power bank port
Color: Black, Rose Gold
App: Atomberg Home
Compatible door thickness: 28-65 mm
Bluetooth range: Upto 40 ft.
Operating Ambient Temperature: -10 to 55 degrees C
Maximum number of Fingerprints: 100
Low battery Alarm: < 4.5V
Operating Current: <250 mA
Standby Current: <85 uA
Test Rating: IP54 Rating (Dust & Water Resistant)
Tested for 50,000 Unlock Cycles (25000 on each side)
Manufacturer: Atomberg Technologies Limited (Formerly known as Atomberg Technologies Private Limited),Mind Space Shelters LLP/ Vithai Developers LLP, Gate No. 51-59, Village Bhamboli, Chakan, Pune, Maharashtra-410507
Packer: Atomberg Technologies Limited (Formerly known as Atomberg Technologies Private Limited),Mind Space Shelters LLP/ Vithai Developers LLP, Gate No. 51-59, Village Bhamboli, Chakan, Pune, Maharashtra-410507
Marketed By: Atomberg Technologies Limited (Formerly known as Atomberg Technologies Private Limited)
3rd Floor, Tower B, 247 Embassy Park, LBS Marg, Vikhroli West, Mumbai, Maharashtra, India, 400083
Customer Service: For any Complaints/Comments on quality, please write to the Manager, Consumer care cell address of regd.office- 3rd Floor, Tower B, 247 Embassy Park, LBS Marg, Vikhroli West, Mumbai, Maharashtra, India, 400083 or call 8448449442 or email to [email protected]
Country of Origin: China
Net Quantity: 1 Count
